LF622UFT
Lead Free* Full Port Tapped Union End Ball Valves
Series LF622UFT Lead Free* full port tapped union end ball valves are designed for steam service applications. They are ideal for throttling and balancing of nonabrasive fluids where minimum flow is 20% to 100% of valve capacity. The full port design ensures minimal pressure drop. These valves feature a PTFE stem packing seal, thrust washer, and seat. They are available with tapped outlets suitable for the installation of a pressure gauge or test cock. Maximum working pressure: 600psi (41.3 bar) WOG; 125psi (8.6 bar) WSP.
Features
- Available with tapped side outlet suitable for installation of pressure gauges or test cocks
- Lead Free* construction to comply with Lead Free* installation requirements
- Tee handle standard on 1⁄2" through 11⁄4" sizes (15mm – 32mm)
- Lever handle standard on 11⁄2" through 2" sizes (40mm – 50mm)
Literature
Approval/Certification Information
For product-specific approval information, please refer to the product’s specification sheet (see literature section above) or ask a Watts representative. For general information regarding any approval certification partners identified in the specification sheet, please visit our certification partners’ websites:
| ASSE | CSA | FM Approvals | NSF |
| UL | ULC | USC | WQA |
