LF767FR
Lead Free* Freeze-Resistant Pressure Vacuum Breaker Backflow Preventers
Series LF767FR Lead Free* freeze-resistant pressure vacuum breaker backflow preventers are designed to prevent backsiphonage of contaminated water under continuous Pressure into the potable water supply. Its superior design protects the valve body and internal components during sudden freeze conditions. Water inside the PVB freezes from the outside-inward. As the ice forms and expands causing a buildup of pressure, the LF767FR relieves the pressure through a unique relief valve built into the plastic float. Test cocks are positioned at the lowest point of the valve for winterization draining. They feature a bronze body. Maximum working pressure is 150 psi (10.3 bar).
Features
- Prevents backsiphonage of contaminated water under continuous pressure into the potable water supply
- Unique built-in relief valve relieves pressure caused by ice formation
- Test cocks positioned for easy testing and winterization
- Sizes 1⁄2 in. - 2 in. (15mm - 50mm)
Literature
Approval/Certification Information
For product-specific approval information, please refer to the product’s specification sheet (see literature section above) or ask a Watts representative. For general information regarding any approval certification partners identified in the specification sheet, please visit our certification partners’ websites:
| ASSE | CSA | FM Approvals | NSF |
| UL | ULC | USC | WQA |
